Impressive Hot Water Tank for medium sized families.

With the ability to provide consistent hot water for up to 4-5 people, the Rinnai 160L Electric Hot Water System perfectly suits installations for medium-sized households and dwellings.

Designed for peace-of-mind, the hot water tanks are thermostatically controlled with safety temperature shut off and the unique blend of enamel and enhanced sacrificial anode protection extends its lifespan.

Featuring single or twin element configurations, standard sizing for emergency changeovers and with internal / external applications available, updating existing or installing new hot water tanks is a breeze with minimal changeover costs.

Features

• Available in QLD & WA only
• Flexible installation options
• Perfect for medium sized families
• 10 year cylinder warranty
• Slim and compact models available
• Vitreous Enamel lined steel tank for added durability
• Inbuilt anode protection extends the life of the tank
• Dual handed, allows increased flexibility during installation
• Pressure temperature relief valve included
• Suitable for internal and external use
• Thermostatically controlled with safety temperature shut off for added peace of mind
• Single and Twin element available on 160L

Specifications

• Electrical Supply AC 240V 50Hz
• Tank Diameter 515
• Heating Elements Available (kW) 1.8 / 2.4 / 3.6
• Packaged Weight (kg) 71
• Overall Height 1530
• Outlet Height 1310
• Inlet Height 225
• Electrical Connection Height – Lower (mm) 155
• Electrical Connection Height – Upper (mm) 946
• Relief Valve Setting (kPa) 1000
• Expansion Control Valve Setting (kPa) 850
• Max inlet pressure (with ECV – kPa) 680
• Max inlet pressure (without ECV – kPa) 800
• Water Connections RP 3/4 20mm
• Ingress Protection Rating (AS1939) IPX4
• Rated Capacity (Litres) 160
